Product introduction:
The EV Charger 48V revolutionizes mid-power charging with its dual-mode voltage platform (32-64V/0-68V adjustable), delivering 60A/3200W output. Its patented adaptive algorithm automatically identifies battery chemistry (Li-ion/Pb-acid) . Engineered for maximum energy savings, the charger achieves 93% peak efficiency - 15% more efficient than conventional models - while maintaining an industry-leading 0.99 power factor (CE-ErP certified). Its intelligent thermal management system enables full 60A output even at 45°C ambient temperatures, supported by vortex cooling fan technology for near-silent operation (<45dB@1m). The 3U rack-mountable form factor allows for high-density deployment in charging stations, while 200% surge capacity and IP20 protection ensure reliable operation in harsh environments. Whether for electric utility vehicles, AGV fleets, or off-grid telecom systems, the EV Charger 48V delivers faster, smarter, and more efficient charging performance.
Product Feature
Auto-Voltage Detection
Seamless switching between 32-64V/0-68V modes
01
Military-Grade Durability
200% surge capacity + IP20 + forced-air cooling
02
Energy Efficiency Leader
93% conversion efficiency + 0.99 PF (CE-ErP certified)
03
High-Density Design
3U form factor for rack-mounted deployment
04
Silent Operation
Vortex cooling fan technology (<45dB@1m)
05
Product Application
◆Special vehicle charging：Police patrol car/ATV can be recharged quickly (charging to 80% in 30 minutes)
◆Intelligent storage system supports 24-hour uninterrupted rotation charging of AGV cluster
◆Off-grid power system provides charging guarantee for communication base stations in extreme environment at -40℃.
Why Choose EV Charger 48V?
Adaptive Charging - Automatically adjusts for different battery types
Rapid Deployment - 30-minute fast charge capability for emergency vehicles
Energy Optimized - Saves 15%+ power vs. conventional chargers
Extreme Environment Ready - Operates from -20°C to 45°C
Silent Operation - Library-quiet (<45dB) for indoor use
FAQ
What kinds of batteries are compatible with this 3200W charger?
Our 3200W charger is suitable for lithium-ion and lead-acid battery packs. It supports intelligent charging curves for different chemistries and can be customized upon request.
Can the output voltage be adjusted?
Yes. The output voltage range is 32V–64Vdc (up to 68Vdc). We can preset or make it adjustable according to your battery specifications.
What protection functions are included?
Protection includes Over-voltage, Over-current, Over-temperature, Short-circuit, and Reverse polarity protection. Protection grade is IP20.
How is the charger cooled?
It adopts forced air cooling with a built-in temperature-controlled fan that automatically adjusts speed according to internal temperature.
Hot Tags: ev charger 48v, China ev charger 48v manufacturers, suppliers, factory, charging solution, Electric scooty scooter, Electrical Scooter Charger, Motorbike Charger, Sightseeing trolley charger, Two wheeled EV Charger
Product Specification
|
Input voltage range |
90~265V |
|
Max input input current |
18A Max |
|
Output rated voltage |
48Vdc |
|
Output voltage range |
32Vdc-64Vdc |
|
Power Factor |
≥0.99 |
|
Maximum output Current |
60A |
|
Efficiency |
≥93% |
|
Input voltage range |
90Vac to 265Vac |
|
Operating temperature |
-20°C~45°C |
|
Storage temperature |
-40°C~70°C |
|
Protection Level |
IP20 |
|
Cooling |
Forced Air Cooling |
|
Dimensions |
274*102*84mm |
