Product introduction:
The TPT130D5412A is a high-performance Dual Channel Industrial Power Board designed to provide stable and reliable dual-output power (54V/2.2A and 12V/1A). It is engineered for industrial automation, telecommunications, and control systems where precise power delivery and durability are critical.
As a Dual Channel Industrial Power Board, this product excels in environments requiring robust power management, offering advanced protection features and compliance with international safety and EMC standards. Its compact design and high efficiency make it ideal for integration into space-constrained industrial equipment.
Product Feature
Dual Output Channels
Provides 54V/2.2A and 12V/1A outputs, catering to systems requiring multiple voltage rails.
Tight voltage tolerances (±1% line regulation, ±2% load regulation) ensure consistent performance.
01
High Efficiency & Low Standby Power
Efficiency up to 84% at full load (230VAC input), reducing energy consumption.
Standby power loss ≤2.0W at no load, enhancing energy savings.
02
Robust Protection Mechanisms
Hiccup-mode over-current protection (54V: 3A–5A) and latch-mode over-voltage protection (54V: 58V–65V).
Short-circuit protection with auto-recovery, ensuring system safety.
03
Wide Input Voltage Range
Supports 90VAC to 264VAC input, adaptable to unstable power grids and global voltage standards.
04
Industrial-Grade Reliability
Operates in -10°C to +40°C and withstands vibrations (5G) and shocks (20G).
MTBF > 44,000 hours at 25°C, ensuring long-term durability in harsh environments.
05
Product Application
Industrial Automation
Power for PLCs, motor drives, and control systems.
Telecommunications
Backup power for base stations and network infrastructure.
LED Lighting
High-voltage LED arrays and driver circuits.
Test & Measurement Equipment
Precision instruments requiring stable dual-voltage inputs.
Why Choose This Power Board?
- Dual-Output Design: Simplifies power architecture by replacing multiple single-output PSUs.
- Energy Efficient: High efficiency and low standby power reduce operational costs.
- Industrial Durability: Built to withstand harsh conditions, including high vibrations and wide temperature ranges.
- Easy Integration: Standard 3.96mm connectors and clear pin definitions streamline installation.
- Proven Reliability: 44,000+ hours MTBF ensures uninterrupted operation in critical applications.
Hot Tags: dual channel industrial power board, China dual channel industrial power board manufacturers, suppliers, factory, 250w power board, 560W Dual Output with Thermal Protection, Compact 166W 54V Redundant PSU Module, Dual Channel Industrial Power Board, Heavy Duty Switching Power Module, Server Grade Power Supply Board
Production Specification
1. Input Characteristics
| Parameter | Specification | Conditions / Notes |
|---|---|---|
| Input Voltage Range | 90Vac to 264Vac | - |
| Normal Voltage Range | 100Vac to 240Vac | - |
| Standby Power Loss | ≤ 2.0W | @ 100Vac, No Load |
| Max Input AC Current | 2.0 A max | @ Full Load |
| Inrush Current | 80 A max | Cold Start, 230Vac |
| Efficiency | 84% | @ 230Vac, Full Load |
| Leakage Current | < 3.5 mA | @ 230Vac |
| Input Fuse | T5A / 250Vac | - |
2. Output Characteristics
Output Voltage & Current Range
| Output | Min Voltage | Nominal Voltage | Max Voltage | Max Current | Conditions |
|---|---|---|---|---|---|
| Vout1 | 52.5V | 54V | 55.5V | 2.2A | Vin=100-240Vac |
| Vout2 | 11.4V | 12V | 12.6V | 1.0A | Vin=100-240Vac |
Output Performance
| Parameter | Vout1 (54V) | Vout2 (12V) | Conditions |
|---|---|---|---|
| Line Regulation | ±1% | ±1% | Vin=100-240Vac, Full Load |
| Load Regulation | ±2% | ±2% | Vin=100-240Vac, Full Load |
| Voltage Tolerance | ±5% | ±5% | Vin=100-240Vac, Full Load |
| Ripple & Noise | 500 mVp-p | 120 mVp-p | @ 25°C, 20MHz BW |
| Transient Response | ±5% | ±5% | Load Change: 25%-75% |
| Overshoot | ±5% | ±5% | Iout=0A to Max |
| Turn-on Time | 3 s | 2 s | Vin=230Vac, Full Load |
| Output Hold Time | 10 ms | 10 ms | Vin=100Vac, Full Load |
| Output Rise Time | 20 ms | 20 ms | Vo=10%-90%, Full Load |
3. Protection Functions
| Protection Type | Vout1 (54V) | Vout2 (12V) | Mode |
|---|---|---|---|
| Over Current (OCP) | 3.0A - 5.0A | No OCP Function | Hiccup, Auto-recovery |
| Short Circuit (SCP) | - | - | Hiccup, Auto-recovery |
| Over Voltage (OVP) | 58V - 65V | - | Latch |
4. Environmental & Reliability Specifications
| Category | Parameter | Specification |
|---|---|---|
| Lifespan | Product Life (E-CAP) | > 5 Years (44,000 hours) @ 25°C |
| Reliability | MTBF | > 44,000 Hours @ 25°C |
| Temperature | Operating Temperature | -10℃ to +40℃ |
| Storage Temperature | -20℃ to +70℃ | |
| Humidity | Operating Humidity | 10% to 90% RH (Non-condensing) |
| Storage Humidity | 5% to 95% RH (Non-condensing) | |
| Altitude | Operating Altitude | Up to 10,000 ft (≈ 3,048 m) |
| Storage Altitude | Up to 20,000 ft (≈ 6,096 m) | |
| Cooling | Method | Natural Convection (Fanless) |
